Product details
An F4-class flight controller built for tool-free assembly, fully NDAA-compliant. Locking JST-GH connectors replace solder pads throughout, so the whole stack goes together without a soldering iron. Two camera inputs switch on the fly via R/C control, and a dedicated payload connector with GHST passthrough keeps auxiliary devices wired in cleanly.
Features
- STM32F405 processor
- Betaflight and iNav support
- Two camera inputs, switchable via R/C control
- Single-sided 30 × 30 mm mounting layout
- Locking JST-GH connectors throughout
- USB-C for configuration and firmware
- Choice of IMU (MPU-6000 or BMI270)
- Onboard OSD
- Twin 2 A switching regulators (5 V and 10 V)
- 16 MB onboard serial flash memory
- 4 or 8 motor outputs
- SIK radio interface
- Payload connector with GHST passthrough, UART, and GPIOs
- GPS/magnetometer connector
- Onboard barometric altimeter
- Onboard beeper
- Full NDAA compliance — designed and manufactured in the EU
Specifications
| Processor | STM32F405 |
| IMU | MPU-6000 or BMI270 |
| Camera inputs | 2, R/C switchable |
| Motor outputs | 4 or 8 |
| Radio interface | SIK |
| Regulators | Twin 2 A switching — 5 V and 10 V |
| Flash memory | 16 MB serial flash |
| Altimeter | Onboard barometric |
| USB | USB-C |
| Connectors | JST-GH (locking) |
| Payload connector | GHST passthrough, UART, GPIOs |
| GPS | Dedicated GPS/magnetometer connector |
| Mounting | 30 × 30 mm, single-sided |
| Firmware | Betaflight, iNav |
| Compliance | NDAA compliant, designed and manufactured in the EU |
What's in the box
1× ORQA F405 3030 FC · Softmount gummies
